Product Details
Concealed Hinges, or Euro Hinges, are the benchmark for modern cabinetry, blending a seamless aesthetic with advanced functionality for kitchens, wardrobes, bath vanities, and commercial furniture. Precision-engineered with a 35 mm cup and 3-way adjustment, these hinges provide optimal door alignment and smooth movement.
Versatile options—such as soft-close, push-to-open, clip-on, and glass door types—fulfill both residential and commercial needs. Crafted from corrosion-resistant materials and rigorously cycle-tested, they meet global performance and quality standards.
Product Types: Full Overlay, Half Overlay, Inset, Soft-Close, Push-to-Open, Clip-On, Glass Door hinges
Material Options: Cold-rolled steel (CRS), Stainless steel (SS304), Brass-plated steel
Available Sizes: Standard 35 mm cup (26 mm mini); cup depth 11.5 mm; opening angles 105°, 110°, 165°, 180°
Performance Specs: ±0.1 mm tolerance; 50,000+ cycle tested; load capacity 5–7 kg per hinge set
Finish Options: Nickel-plated, Chrome, Matte Black, custom on request
Quality Grades: Standard grade for commercial furniture; premium for luxury/export markets
Certifications: ISO 9001:2015, EN 15570, BIFMA standards
Customization: Logo stamping, special finishes, custom packaging, non-standard angles
Special Features: 3-way adjustment (height, side, depth); integrated soft-close damper; quick clip-on/off mounting plates
